Critical care ultrasound machines, proven on real ICU scans
Ten unedited captures show what a handheld reads in critical care: B-lines, pericardial fluid, the caval window and the vessel a line goes into. Published pricing, software included, no subscription.
Every scan on this page was recorded on this Suresult hardware family, by clinicians who bought it and by a clinical trainer who scans with it. Each clip is trimmed to the scan itself. ·Trusted by 8,717 clinicians →
簡単な回答
A critical care ultrasound machine is a bedside scanner that reads lung water, pump function, volume status and vessel anatomy without moving the patient.
- The D3 family carries phased, convex and linear heads in one probe: the heart, the caval window, the pleural line and the neck vessels on one device.
- Color Doppler, pulsed-wave Doppler and M-mode ship on every scanner on this page, and the L10SH and D3Ultra add ニードルエンハンス to the puncture guides.
- Stills and cine loops export from the app as DICOM, JPEG, PNG or MP4, so an ICU study reaches the record without a cart.
- The D3Pro and D3L scan for three hours continuously on a 4,200 mAh battery, which covers a full ward round.
The capture atlas
Ten real critical care windows, captured on Suresult handheld hardware
Unedited clinical captures · select any image to enlarge
3 windows3 windows
Diffuse B-lines in acute pulmonary edema on the D3Ultra
Vertical artifacts rise from the pleural line and run to the bottom of the sector, the pattern that separates cardiogenic edema from an obstructive cause of dyspnea. The case note describes an end-stage renal disease patient with orthopnea and hypoxia who improved after urgent dialysis.
8.3-second cine loop on a D3Ultra, submitted by the treating buyer with the case note
Pleural effusion with atelectasis
An anechoic collection sits above the diaphragm with collapsed lung floating inside it. This is the finding that a supine chest film misses most often, and it decides whether a drain goes in.
captured on a Suresult wireless probe in the shared clinical reference library; on-screen header reads 86 dB gain, 160 mm depth, harmonic 5.0 MHz
The pleural line, the reference for every lung window
A bright horizontal line with A-lines repeating below it is the normal aerated pattern. Gain and depth are set on this view before any anterior or posterior zone is scored.
captured on a Suresult wireless probe in the shared clinical reference library; on-screen header reads 83 dB gain, harmonic 5.0 MHz3 windows3 windows
Pericardial effusion on the D3Ultra
An anechoic rim surrounds the heart through the whole cardiac cycle. The buyer found it incidentally in a dialysis patient, and it is the ICU finding that most often changes management inside the hour.
6.7-second cine loop on a D3Ultra, submitted by the treating buyer with the case note
Apical four-chamber view on the PD1
All four chambers open from the apex on a dedicated phased-array head. This is the window for a visual estimate of ejection fraction and for comparing the two ventricles in shock.
6.9-second buyer clip on a PD1, submitted by Ana Lucia Telleria Torres
Parasternal long axis with M-mode on the CD2
The sector shows the left ventricle, the mitral and aortic valves and the left atrium, with an M-mode trace timing wall motion below it. One dual-head probe covered this and the abdominal window in the same session.
6.6-second buyer clip on a CD2 at 3.6 MHz, submitted by Felipe Jaramillo2 windows2 windows
Inferior vena cava on the D3Ultra
The caval lumen runs through the liver, labeled Vena Cava on screen by the scanning physician. Caval diameter and respiratory collapse read volume status before a fluid bolus is committed.
still frame on a D3Ultra at 3.2 MHz, dated 2025-10-19, from a German buyer's own case folder
Perihepatic free fluid
An anechoic collection sits in the perihepatic space, bordering the liver. The same convex window that measures the caval vein answers the free-fluid question on the way past.
captured on a Suresult wireless probe in the shared clinical reference library; on-screen header reads 80 dB gain, 200 mm depth, harmonic 5.0 MHz2 windows2 windows
Common carotid artery and internal jugular vein in long axis
The carotid artery and the internal jugular vein run across the field with parallel walls in long axis. This is the plane an in-plane needle follows, so the shaft and the tip stay in view during cannulation.
captured on a Suresult wireless probe in the shared clinical reference library; on-screen header reads 40 mm depth, 7.5 MHz
Moderate right hydronephrosis on the D3Ultra
The renal pelvis and calyces are dilated in the longitudinal plane. Obstruction is the reversible cause of acute kidney injury that a bedside scan finds before the creatinine trend explains itself.
still frame on a D3Ultra, dated 2026-06-19; the buyer's case note reports an obstructing stone confirmed afterwardsSelect a card to switch capture
Technique basics
How the exam comes together, probe to report
Match the head to the ICU question.Cardiac windows sit between the ribs, so they need the phased sector. The convex head reaches the abdomen and the caval window, and the linear head images the pleural line and the neck vessels.
The convex and phased face on the D3Ultra- Start with the lung in respiratory failure.
Set gain and depth on the pleural line first. Anterior zones separate A-lines from diffuse B-lines, and posterior zones find effusion and consolidation.
Pleural line at harmonic 5.0 MHz - Read the heart, then the caval window.
The phased head shows pump function and pericardial fluid at 160 mm to start. The convex head then measures caval diameter and collapse before a fluid bolus is committed.
IVC at 3.2 MHz on the D3Ultra
Place the line on the linear head.In-plane and out-of-plane puncture guides draw the needle path over the vessel, and the flip and grid tools keep the orientation honest. Needle Enhance sharpens the shaft on the L10SH and the D3Ultra.
Puncture assist in the app
What the research says
The evidence, three studies checked
- Lung ultrasound outread the bedside chest film in ARDS.
In 32 patients with ARDS, lung ultrasonography was 93% accurate for pleural effusion and 97% for alveolar consolidation, against 47% and 75% for bedside chest radiography.
Lichtenstein et al., Anesthesiology 2004 - A bedside protocol changed the admitting diagnosis in one ICU patient in four.
In 125 consecutive ICU admissions scanned under a critical care ultrasonography protocol, findings modified the admitting diagnosis in 25.6% of patients and changed therapy in 17.6%.
Manno et al., Anesthesiology 2012 - Ultrasound guidance beat the landmark technique for internal jugular lines in the ICU.
Ultrasound-guided internal jugular cannulation succeeded in all 450 ICU patients, against 94.4% with the landmark technique, which punctured the carotid artery in 10.6%.
Karakitsos et al., Crit Care 2006
Pick your model
Pick the model that fits your day
MOST CHOSENOne scanner for the whole ICU roundD3Ultra
One scanner for the whole ICU roundD3UltraThe D3Ultra carries phased, convex and linear heads in one probe, with 192 elements and 64 channels. Most of the atlas above came off this model, from lung B-lines to the caval window.
heads in one probe, one probe
$2,976 D3Ultra · Convex Linear Phased MultipuBuy nowD3Ultraを見る
Echo and central lines are the daily workシーディーツーThe CD2 pairs a 2.2/3.6 MHz phased head with a 7.5/10 MHz linear head in a 150 g body, across 192 elements and 64 channels. Cardiac windows to 190 mm and vascular access sit on the same probe.
150 g, phased + linear
$2,697 CD2 · Phased Linear Dual-Head UltrBuy nowView CD2 →
Long rounds without a chargerD3プロThe D3Pro scans for three hours continuously on a 4,200 mAh battery and carries the same three probe formats. Its convex and phased heads reach 305 mm.
three hours continuously, three formats
$2,697 D3Pro · Dual-Head 3-in-1 Wireless UlBuy nowView D3Pro →スキャナーの比較
Seven Suresult handheld scanners for critical care, compared
Swipe to see all columns →
| モデル | 価格 | 頻度 | 深さ | 最適 |
|---|---|---|---|---|
| D3Ultra | $2,976 | Phased 3.2/5.0 + convex 3.2/5.0 + linear 7.5/10 MHz | Phased and convex 90-300 mm, linear 20-100 mm | The full ICU exam on one 192-element probe, 64 channels, 2-hour battery |
| D3プロ | $2,697 | Phased 3.2/5.0 + convex 3.2/5.0 + linear 7.5/10 MHz | Phased and convex 90-305 mm, linear 20-80 mm | Three formats with a 3-hour battery for long rounds, 192 elements |
| シーディーツー | $2,697 | Phased 2.2/3.6 + linear 7.5/10 MHz | Phased 90-190 mm, linear 20-100 mm | Echo plus vascular access at 150 g, 192 elements and 64 channels |
 L10SH | $3,534 | Linear 7.5/10 MHz | 20/40/60/100 mm | Line placement and lung windows, 256 elements with Needle Enhance |
 D3L | $2,418 | Phased 3.2/5.0 + convex 3.2/5.0 + linear 7.5/10 MHz | Phased and convex 90-305 mm, linear 20-80 mm | Three formats with an 80-degree phased sector and a 3-hour battery |
 D3 | $2,232 | Phased 3.2/5.0 + convex 3.2/5.0 + linear 7.5/10 MHz | Phased and convex 90-305 mm, linear 20-100 mm | The entry three-format handheld at 150 g, cable or Wi-Fi |
 ピーディーワン | $2,139 | Phased 2.5/2.8/3.6 MHz | 90-190 mm | A dedicated cardiac head, 128 elements and an 80-degree sector |
Against the known brands
Suresult vs Clarius PAL HD3, Butterfly iQ3 and GE Vscan Air SL for critical care
Swipe to see all columns →
| スレ | クラリアスPAL HD3 | バタフライiQ3 | GE Vscan Air SL | |
|---|---|---|---|---|
| ICU imaging | Phased, convex and linear heads in one probe on the D3 family. Phased depth 90-305 mm on the D3Pro, D3L and D3. 192 elements and 64 channels on the D3Ultra, 256 elements on the L10SH. | 1-15 MHz dual array, 307 g | 1-12 MHz single chip, 30 cm on the abdomen preset and 25 cm on cardiac presets, 300 g | Sector phased plus linear dual probe |
| Device price | $2,139 to $3,534, published on each product page | $5,395 published | $3,899 published | Starting at $4,999 published |
| サブスクリプション | None. Software is included with the scanner. | Clarius Essentials is $695 a year, $1,785 for three years or $2,500 one time | Core is $299 a year, Advanced is $420 a year, or $1,500 once for five years of Advanced | Digital Tools for Vscan Air is sold as a separate software package from the scanner |
| Landed cost | Duties and shipping included in the checkout price, 1-7 day delivery | US list price; duties and shipping extra outside the US | US list price; duties and shipping extra outside the US | US list price; duties and shipping extra outside the US |
| Continuous scanning | 3 hours on the D3Pro and the D3L, on a 4,200 mAh battery, and 2 hours on the D3Ultra | Scan time about 60 minutes | Battery life up to 2 hours | 50 minutes of continuous scan time |
| Regulatory registrations | FDA 510(k) · ISO 13485 · EU MDR (CE) · TGA · ANVISA · Health Canada | FDA 510(k) | FDA 510(k) | FDA 510(k) |
Where Suresult wins
- Ten critical care windows on this page are unedited captures from Suresult hardware, from lung B-lines to the internal jugular vein.
- Color Doppler, pulsed-wave Doppler, M-mode, measurements and DICOM export ship with every scanner on this page at no extra charge.
- There is no membership to renew.Clarius Essentials costs $695 a year and Butterfly Advanced costs $420 a year.
- The checkout price is the landed price: duties and shipping are included, with 1-7 day delivery.
- The D3 family carries phased, convex and linear heads in one probe, so the heart, caval window, lung and vessels stay on one device.
- The D3Pro and the D3L scan for three hours continuously on a 4,200 mAh battery, which covers a full ICU round on one charge.
- The L10SH carries a 256-element linear array with Needle Enhance for cannulation, at 150 g.
- Suresult scanners are registered under FDA 510(k), ISO 13485, EU MDR (CE) and Health Canada.
The five-year math
Clarius Essentials at $695 a year reaches $3,475 by year five, on top of the $5,395 PAL HD3. Butterfly's Advanced plan is $420 a year, which is $2,100 over the same five years, or $1,500 paid once. Suresult scanners carry no membership.
D3Ultra, paid onceClarius PAL HD3: scanner + membership= $3,475 in fees alone by year five
Three models, one decision
Not sure which model fits your cases?
One conversation gets a direct recommendation: the right Suresult probe, or a straight “neither.”
集中治療医と救急医のためのトップ・チョイス携帯型超音波診断装置
血行動態評価を合理化し、重要な手順を導き、放射線検査を待つことなく生命を脅かす状態を可視化します。
D3Ultra
D3Ultra凸型リニアフェーズド多目的ハンドヘルド超音波
頻度： コンベックス/フェーズドプローブ 3.2/5.0MHz リニアプローブ 7.5/10MHz
スキャンの深さ リニア：20-100mm、コンベックス＆フェーズド：90-300mm
クリティカルケア
buy scanner
D3プロ
D3Pro Dual-Head 3-in-1 Wireless Ultrasound Scanner
頻度： コンベックス/フェーズドプローブ3.2/5.0MHz、リニアプローブ7.5/10MHz
スキャンの深さ コンベックス/フェーズドプローブ：90-305mm、リニアプローブ：20-80mm
クリティカルケア
buy scanner
シーディーツー
CD2 カラー・ドップラー付きフェーズド・リニア・デュアルヘッド超音波192素子
頻度： フェーズドプローブ2.2/3.6MHz、リニアプローブ7.5/10MHz
スキャンの深さ フェーズドプローブ90-190mm、リニアプローブ：20-100mm
クリティカルケア
buy scanner
クリティカルケア用ハンドヘルド超音波を購入する前に考慮すべきこと
汎用性の高いプローブ、シームレスな画像処理、一日中使用できる臨床的信頼性など、ICUや救急外来に最適な装置をお選びください。
Before you buy
購入前のチェックポイント
What is the best handheld ultrasound machine for critical care?
The Suresult D3Ultra fits most intensive care units, because it carries phased, convex and linear heads in one 192-element probe. The CD2 suits units where echocardiography and central lines are the daily work.
Which point-of-care ultrasound exams are standard in the ICU?
Lung ultrasound, focused echocardiography, inferior vena cava assessment, abdominal free-fluid scanning and ultrasound-guided vascular access are the five exams this page demonstrates. All five run on one handheld probe.
Can a handheld ultrasound replace a cart machine in the ICU?
A handheld answers the focused ICU questions: lung water, pump function, effusion, volume status and line placement. Comprehensive echocardiography, transesophageal imaging and full Doppler quantification stay on a cart system.
Is lung ultrasound more accurate than a bedside chest radiograph in ARDS?
A 2004 Anesthesiology study of 32 patients with ARDS found lung ultrasonography 93% accurate for pleural effusion, against 47% for bedside chest radiography.
How often does a bedside ultrasound change the ICU diagnosis?
In 125 consecutive ICU admissions scanned under a critical care ultrasonography protocol, findings modified the admitting diagnosis in 25.6% of patients and changed medical therapy in 17.6%.
Does ultrasound guidance reduce central line complications?
A randomized study of 900 critical care patients found carotid artery puncture in 10.6% of landmark internal jugular attempts, significantly more than in the ultrasound-guided group.
How much does a critical care ultrasound machine cost?
A Suresult handheld for critical care runs from $2,139 to $3,534 with software included. The Clarius PAL HD3, Butterfly iQ3 and GE Vscan Air SL publish $3,899 to $5,395 before any membership fee.
Which model covers the whole shock assessment?
The D3Ultra and the D3Pro carry phased, convex and linear heads in one probe. That covers the cardiac, caval, abdominal and lung windows of a shock assessment.
What imaging depth do adult ICU cardiac windows need?
Suresult phased heads reach 190 mm on the CD2 and the PD1, 300 mm on the D3Ultra and 305 mm on the D3Pro, D3L and D3. Every one of those ranges covers adult apical and subcostal windows.
Is there a subscription fee on a Suresult scanner?
Suresult scanners carry no subscription. Clarius Essentials is $695 a year, and Butterfly's Advanced plan is $420 a year or $1,500 once for five years.
Can an ICU study go into the patient record?
The seven models on this page save stills and cine loops of 100 to 1,000 frames in the app, and export them as DICOM, JPEG, PNG or MP4.
How long does the battery last on an ICU round?
The D3Pro and the D3L scan for three hours continuously on a 4,200 mAh battery. The D3Ultra runs two hours, and the CD2 and L10SH run 90 minutes.
Does the same probe do lung imaging and line placement?
The linear head images both the pleural line and the neck vessels. On the L10SH that head is a 256-element array with Needle Enhance for cannulation.
How is a handheld probe cleaned between ICU patients?
The probe is wiped after each use with a soft cloth dampened with isopropyl alcohol, for one minute or until it is visibly clean. For wipe disinfection the user manual lists T-spray II, a quaternary ammonium agent, at under 10 minutes of contact time.
Which Suresult model is the cheapest way into ICU echocardiography?
The PD1 is the entry phased-array model, with 128 elements, 2.5/2.8/3.6 MHz and 90 to 190 mm of depth, at $2,139.
Does a handheld work for mechanically ventilated patients?
A 2004 Anesthesiology study of 32 patients with ARDS found lung ultrasonography 97% accurate for alveolar consolidation, against 75% for bedside chest radiography. Lung ultrasonography also quantified the extent of lung injury, which chest radiography could not.
フェーズドアレイプローブ（周波数3～5MHz）
心機能、IVCの変動、心嚢液貯留を迅速かつ正確に評価すること。
Linear Array Probe (7–10 MHz)
明確なバスキュラーアクセス、気胸、FAST検査用。
コンベックス・アレイ・プローブ (2-5 MHz)
For deep abdominal and pelvic imaging and procedural guidance with a wide field of view.
カラードップラーとパワードップラー
ハイリスク患者の灌流、DVT、血管異常を明確に評価するため。
頑丈で消毒可能なデザイン
ICU、隔離ユニット、現場対応シナリオなど、リスクの高い環境での迅速な展開に。
Instant Wireless Image Sharing with PACS and DICOM Integration
For real-time collaboration and efficient documentation.
フリーソフト、
無制限スキャン
Suresultのハンドヘルド超音波診断装置には、追加費用なしで無制限の機能を提供する強力なソフトウェアが付属しています。無料のDICOMとパルス波ドップラーに加え、iOS、Android、Windowsのユーザーフレンドリーなインターフェースをお楽しみください。
フルプラットフォーム対応、ライフタイム 無料アップグレード
細部まで撮影、正確にガイド、簡単に共有
オールインワンソリューションで超音波検査のワークフローを改善します。すべてのスキャンで、正確さ、シンプルさ、効率性を実感してください。
17以上の専門プリセット
コンベックス / フェーズドプローブ
リニアプローブ
27 精密診断のための自動測定
迅速でリアルタイムな評価のためのツール一式で作業を簡素化します。
Bモード
- 長さ、面積/円周、角度、トレース、距離
- Depth and angle readouts for needle and injection guidance
- Obstetric biometrics (gestational age, EFW) when your caseload needs them
B+Mモード
- 心拍数、時間、距離
- 左室内径（LVIDd、LVIDs）
- 駆出率（EF）、ストローク量（SV）
B+PWモード
- 速度、心拍数、S/D比、深度
- 自動容器流量測定
- 収縮期ピーク速度(PS)、拡張末期速度(ED)
- 時間平均最大速度(TAMAX)、時間平均平均平均速度(TAMEAN)
- 脈動指数（PI）、抵抗指数（RI）
- 容器直径（DIAM）、流量（FL）
シネループ
最大記録 1000フレーム（≒165秒） 微妙なディテールまでとらえる連続的な動き。
パンクアシスト機能
正確にお楽しみください 面内 そして 面外ガイド 介入時の自信を高めるために
柔軟なファイルエクスポート
でスキャンしたデータを簡単に保存、共有できます。 JPEG、MP4、PNG、またはDICOM フォーマットで、ワークフローとシームレスに統合できます。
Expert Guidance
Talk to a Scanner Specialist
Tell Suresult about your daily workflow and get a personal scanner recommendation with an all-inclusive quote.
- Free scanner-fit consultation — probes, frequency and depth matched to your procedures
- All-inclusive quote — shipping, customs clearance and applicable taxes covered
- Fast delivery — ships within 24 hours, 1–7 days door to door
- ソフトウェアのサブスクリプションは不要です — iOS, Android and Windows apps included
- 30-day returns and 24/7 support
Live chat opens right here — no forms, no waiting.
よくあるご質問
ハンドヘルド超音波は外傷のフルサイズ装置の代わりになりますか？
Yes. With a full range of probes and excellent resolution, as in Suresult devices, handheld ultrasound can perform the FAST, lung, and vascular scans needed in trauma care. Sometimes, they even outperform full-size systems by cutting out setup delays.
ハンドヘルド超音波を初めて使う人の学習曲線は？
Minimal. If you've used ultrasound before, Suresult’s interface will feel familiar, with recognizable icons and measurement tools. For clinicians new to ultrasound, basic point-of-care ultrasound (POCUS) training is usually enough to get started confidently.
Suresult社の超音波検査は、緊急時に心臓の評価を行うことができますか？
もちろんです。フェーズドプローブを搭載したすべてのSuresult装置は、心臓の集中的なビューをサポートし、心拍数、脳卒中量、駆出率、IVCの潰れやすさなどの自動測定を提供します。
What battery life can I expect from a Suresult handheld ultrasound?
Suresultの超音波装置は、フル充電で1.5～3時間のアクティブスキャンが可能です。また、多くのモデルはワイヤレス充電に対応しているため、スキャンとスキャンの間にバッテリーを補充することができ、ダウンタイムを最小限に抑えることができます。
携帯型超音波検査は人工呼吸器管理をサポートできますか？
はい、人工呼吸患者の管理には非常に有用です。通気モニタリング、Bライン、胸水、気胸の検出、横隔膜の動きの評価による離脱のガイドなどに使用できます。
